E-Body Sliding Stem Control Valves Opt

E-Body Sliding Stem Control

The Fisher® E-Body sliding stem globe style control valve is a general purpose valve used for throttling or on-off service for gas and liquid applications. Types ET and ED valves includes a cage guided balanced valve plug, metal to metal seating, or PTFE (ET only) seating for bubble tight shutoff. Types Fisher EZ and ES contain unbalanced valve plugs with metal seating.

Category:

Certifications   :   SIL capable, Fugitive Emission, NACE

Critical Service   :   Noise Abatement, Steam Condition, Erosive, Low Flow, Corrosive, General Service, Outgassing, Flashing

Flow Characteristics   :   Equal percentage, Linear, Special Characterization, Quick Opening

Material   :   Carbon Steel, Stainless, Duplex, Alloy

Operating Temperature   :   Standard Temperature

Pressure Class   :   PN, ASME

Process Connection Type   :   Flanged, Butt Weld, RTJ, Threaded, Socket Weld

Shutoff Class   :   Class IV (FCI 70-2), Class V (FCI 70-2), Class VI (FCI 70-2)

Valve Size   :   NPS 1/2 to NPS 30

Valve Size Standard   :   NPS, DN

» ENVIRO-SEAL™ packing systems that provide an improved stem seal to help prevent the loss of process fluid

» Streamlined flow passages provide excellent capacities and flow

» Rugged cage guiding provides high valve plug stability

» Increased wear resistance of hardened stainless steel trim means longer-lasting service

» Valves are available with dimensions specified by EN/DIN standards

» Unless otherwise noted, references are to NACE MR0175-2002

» Controlled compression of optional seat construction protects PTFE disk between metal disk seat and disk retainer
