Size : 1.5 – 14 inch
Rating : ANSI CLASS 150
Working Pressure : 75PSI – 150PSI
Material : High Impact PVC (HI-PVC)
Temperature : 30°C / 120°F
End : Flanged
Manufacturer : ASAHI, Other Request
PVC Gate Valves are widely used ON/OFF valves for large diameter, full port applications. When the valve is open, it allows a straight-through passage similar to the inside diameter of the connecting pipe providing minimal pressure drop. The valve operates when the hand wheel and stem screw (or electric actuator) move a cylindrical plug (the gate) up and down at right angles to the fluid flow.
Size : 1.5 – 14 inch
Rating : ANSI CLASS 150
Working Pressure : 75PSI – 150PSI
Material : High Impact PVC (HI-PVC)
Temperature : 30°C / 120°F
End : Flanged
Manufacturer : ASAHI, Other Request
» Asahi Valves – 3 year warranty
» Lightweight for easy installation
» All sizes rated for full vacuum service
» No metal to media contact inside the valve
» Straight flow through with minimal pressure drop
» Clean-out functionality is provided via a drain plug located at the bottom of the valve
