Certifications : SIL capable, ATEX, CUTR, PED, CRN, Fugitive Emission, NACE
Critical Service : Noise Abatement, Cavitation, Dirty Service, Erosive, Low Flow, General Service
Flow Characteristics : Equal Percentage
Material : Carbon Steel, Stainless, Duplex, Alloy
Operating Temperature : Standard Temperature
Pressure Class : PN, ASME
Process Connection Type : Flanged
Shutoff Class : Class III (FCI 70-2), Class IV (FCI 70-2), Class VI (FCI 70-2)
Valve Size : NPS 1, NPS 1-1/2, NPS 2, NPS 3, NPS 4, NPS 6, NPS 8, NPS 10, NPS 20
Valve Size Standard : NPS, DN
» Flanged body design eliminates exposed line flange bolting
» The solid HD ball seal construction provides long service life in demanding applications
» Precise contouring of the Vee-Ball provides a modified equal percentage flow characteristic
» Materials are available for applications involving sour liquids and gases
» Ball seal inspection and replacement is done at the valve body inlet
» The one-piece valve body improves structural integrity of the pressure boundary
» The optional ENVIRO-SEAL™ packing systems are designed with very smooth shaft surfaces and live loading to provide exceptional sealing
