The Bray/VAAS Series 940’s one-piece, cast body design offers rugged performance in applications ranging from general purpose to severe media handling. Available with integral metal or replaceable soft seat, the Bray/VAAS Series 940 gate valve is easily automated for on/off applications
Size : 2″ – 36″ (50 – 900mm)
Rating : ASME B16.5 Class 150, ASME B16.47 Class 150
Working Pressure : 100PSI (7Bar), 150PSI (10Bar)
Body Style : Single Piece, Wafer, Lug
Material : Stainless Steel, Carbon Steel, Duplex, Monel
Temperature : 90°C – 650°C / 194°F – 1202°F
Actuator Options : Handwheel, Bevel Gear, Pneumatic, Hydraulic, Electric
Manufacturer : BRAY, Other Request
» Designed for easy, quick conversion between manual and pneumatic actuation
» Clevis design and horizontal bolting stabilizes gate ensuring proper alignment
» Standard multi-layer square packing provides exceptional gland sealing
» Optional energized quad seal packing for enhanced gland sealing
» Standard integral metal seat and optional replaceable zero leakage resilient seats
» Deflection resistant gate design ensures consistent alignment for industry leading durability
