The new generation of ball float steam traps features 13 different EN and ASME end connections and is therefore well suited for a wide range of applications, such as:
» Steam-heated heat exchanger
» Steam lines
» Rotating cylinders
» Gas and compressed air systems
Size : DN 15 -25 (½“–1“), DN 40-65 (1½“–2½“)
Rating : PN 40 / CLASS 300
Material : A105 (A395), A105 A216WCB, F316L CF8M
Temperature : 13.1-43.8 °C / 200-450 bar
End : Flange, Screwed sockets, Socket-weld, But-weld
Manufacturer : GESTRA, Other Request
» Ensures long service life and steam tight shut-off
» Externally adjustable, with separate seat
» Combines large flowrate capacity with steam tight shut-off
» Connections for horizontal or vertical flow direction
» An anti-wear sleeve centers the control unit, protects the trap body and simplifies installation work
» Electrodes installed directly in trap cover
» Manual float lifting lever
» Sightglass cover (UNA 45) PN 16/CL 150
» Externally adjustable internal bypass
» Cover for fitting electrodes (UNA 45) PN 40/CL 300
» Strainer
» Directions of flow: vertical or horizontal (left to right or right to left)
