Steam traps with ball float for removing condensate from steam, cold condensate or distillates without banking-up. The traps with the tried and tested rolling ball seal work with exceptionally low friction and therefore have very low actuating forces.
They are durable and guarantee maximum tightness.
Size : ½” – 6″ DN15 – DN150
Rating : PN16 – PN160 / ANSI Class 125 – Class 300
Working Pressure : 8 Bar – 100 Bar
Material : Cast Steel, Alloy Steel, Cast Iron, Carbon Steel
Temperature : 200°C – 530°C.
End : Flanged, Screwed Socket, Socket-Weld End, Butt Weld
Manufacturer : GESTRA, Other Request
» Unaffected by dirt
» Automatic thermostatic air-venting (Duplex design)
» Unaffected by back pressure and condensate temperature
» No loss of live steam due to continuous water seal at the seat
» No banking-up of condensate even with extreme load and pressure fluctuations
» Particularly well suited for heat exchangers controlled from the steam side
» Steam-regulated heat exchangers
» Steam manifolds
» Systems with a high condensate flowrate
» Steam driers, gas driers, cyclone separators
» Vacuum systems
» Gas and compressed air lines
